KUAIQU DC Lab Power Supply 30V 10A 60V 120V Adjustable Switching Power Supply Encoder Knob Display Regulator For Phone Repairing

【Precise 3/4-digit LED Display】The KUAIQU DC bench power supply has a resolution of 0.01V and 0.001A, and you can easily adjust it in the range of 0-30/60/120V and 0-3/5/10A. The 4-digit back-lit LCD display provides more accurate and clearly visible readings for the voltage and current value, even in conditions of low voltage.

【Small and Diverse Applications】Worried about the bulky power supply? This compact and sophisticated DC power supply weighs much less than a laptop at just 1.3kg, saving more space on your workbench. And you can use it in various scenarios such as laboratory, repair, electrolysis, burn-in test, electroplating, brush plating, electronic DIY, etc.

【Safe and Reliable to Use】Safety is our priority. The DC power supply is FCC/CE certified. The built-in fan low arc noise & low ripple,The power supply is durable and compact. Productive work since the power supply comes multiple protection of Over-voltage, over-current, over-power, over-temperature, short-circuit powerful protection function.

The power supply uses advanced technology PWM, voltage, current can be continuously adjustable from 0 – 30V/60V/120V 0-3/5/10A Rating obtain Ultra-low ripple. High-precision reference voltage source, rational circuit design, the ability to provide highly accurate output. High-power MOS devices Application, to ensure adequate power supply, improve the long-term stability of the power at full load work. Perfect protection function, in order to protect the load And the power supply are not damaged. Simple operation, and a plurality of power supply can be directly connected in series, parallel, expanded power Range of applications.

Application:

1. Factory production testing field：For Production line test.
2.Mobile phone repair field:For Mobile phone、computer repair.
3.Automotive sector:such as charging car batteries, repairing car parts, aging car parts, Car DVD, car audio,etc
4.Electrical appliance maintenance field：Maintenance of various circuit boards, resistors, jewelry,capacitors, relays, DC motors, LEDs,household appliances, and other electrical equipment that require power supply
5.Jewelry field: For electroplating、titanium oxide,etc
6.Battery charging field:Charging lithium batteries,Car Battery ,charging other batteries
7.Drone field: Rapid charging of drones
8.Research laboratory and school field:For Laboratory,scientific research teaching,school ,etc
9.Security monitoring system field:For Security monitoring system, fire protection system, building automation system
10.Modification field:Converting electric bicycles and cars,etc

Features:

1.LCD Screen Protect your eyes (24hours Working) vs LED screen.
2.Have complete operating protection function(Short circuit protection)
3.Highly efficient, low ripple, small volume, light weight
4.Display voltage, current,power, high precision
5.Voltage stabilization, current limiting, simple operation
6.Single voltage input（Dual voltage input easily destroys power supply）We will Send
the correct input voltage power supply according to your country
7.Temperature control fan heat dissipation, low noise
8.Double potentiometer more precise adjustment
9.Output Voltage ranges from 0 to rating voltage with continuous adjustment
10.Output current ranges from 0 to rating current with continuous adjustment

DC Power Supply Specification:

1. Input voltage: 220V 50Hz /110V 60Hz Switch or a single voltage input
2. Output voltage: DC 0- 30V/60V Ratings V (see Table I)
3. Output Current: DC 0-5A/10A rated A (see Table I)
4. Display Accuracy:1% 1 word (three / three and a half digital display, voltage resolution 0.1V, current resolution 0.1A) 0.1% 1 word (four / four semi-digital display, voltage resolution 0.01V, current resolution 0.01A)
5. boot delay: 1-2S Shutdown Delay: 1-6S (depending on the load)
6.Constant pressure state:
Voltage stability ≤ 0.1%+3mV Low voltage: 0.2~0.3%+3mV
Load stability ≤ 0.5%+3mV
Ripple noise: ≤ 30mVrms (effective value)
7.Constant current state:
Current stability ≤ 0.2%+3mA
Load stability ≤ 0.2%+3mA
Ripple noise: ≤ 20mArms (effective value)
8.Display accuracy: 0 5%+2 words
9. Ripple and Noise: CV≤10mV CC≤20mA (RMS)
10. Overall efficiency: ≥80% (under full load test)
11. Working environment: -10 – + 40 Relative humidity 20% -80% (non-condensing)
12. Storage Environment: -20 – + 80 Relative humidity 20% -70% (non-condensing)
13. Pressure test: Input – Output: 1.5KVAC / 1 Minute Input – Housing: 1.5KVAC / 1 Minute Output – Housing: 500VAC / 1 Minute
14. Ground Resistance: <20mΩ
